NG125H - Type C

SKU: bc-627

$64.20

Currently out of stock — contact us for lead times

Ask a Question

Description

Main - 18705 - Miniature circuit-breaker range of product NG125   range Acti 9   product name Acti9 NG125   product or component type Miniature circuit-breaker   device short name NG125H   device application Distribution   poles description 1P   number of protected poles 1   [In] rated current 10 A at 40 °C   network type DCAC   trip unit technology Thermal-magnetic   curve code C   breaking capacity 36 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-236 kA Icu at 12 V DC conforming to EN/IEC 60947-270 kA Icu at 110...130 V AC 50/60 Hz conforming to EN/IEC 60947-236 kA Icu at 125 V DC conforming to EN/IEC 60947-225 kA Icu at <= 144 V DC conforming to EN/IEC 60947-29 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-2   utilisation category Category A conforming to IEC 60947-2   suitability for isolation Yes conforming to IEC 60947-2   Complementary network frequency 50/60 Hz   [Ue] rated operational voltage 380...415 V AC 50/60 Hz125 V DC<= 144 V DC12 V DC220...240 V AC 50/60 Hz110...130 V AC 50/60 Hz   magnetic tripping limit 8 x In +/- 20 %   [Ics] rated service breaking capacity 52.5 kA 75 % conforming to EN/IEC 60947-2 - 110...130 V AC 50/60 Hz27 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz6.75 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz36 kA 100 % conforming to EN/IEC 60947-2 - 60 V DC36 kA 100 % conforming to EN/IEC 60947-2 - 125 V DC   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2   contact position indicator Yes   control type Manual tripping testToggle   local signalling Trip indicatorON/OFF indication   mounting mode Clip-on   mounting support 35 mm symmetrical DIN rail   comb busbar and distribution block compatibility YES   9 mm pitches 3   height 103 mm   width 27 mm   depth 81 mm   net weight 0.24 kg   mechanical durability 20000 cycles   electrical durability 10000 cycles   provision for padlocking Padlockable   locking options description Integrated padlocking   connections - terminals Tunnel type terminals1.5…50 mm² rigidTunnel type terminals1…35 mm² flexible   wire stripping length 20 mm   tightening torque 3.5 N.m   earth-leakage protection Without   Main - 18714 Miniature circuit-breaker range of product NG125   range Acti 9   product name Acti9 NG125   product or component type Miniature circuit-breaker   device short name NG125H   device application Distribution   poles description 2P   number of protected poles 2   [In] rated current 10 A at 40 °C   network type DCAC   trip unit technology Thermal-magnetic   curve code C   breaking capacity 12 kA Icu at 500 V AC 50/60 Hz conforming to EN/IEC 60947-230 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-236 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-270 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-225 kA Icu at <= 250 V DC conforming to EN/IEC 60947-2   utilisation category Category A conforming to IEC 60947-2   suitability for isolation Yes conforming to IEC 60947-2   Complementary network frequency 50/60 Hz   [Ue] rated operational voltage 380...415 V AC 50/60 Hz500 V AC 50/60 Hz220...240 V AC 50/60 Hz440 V AC 50/60 Hz<= 250 V DC   magnetic tripping limit 8 x In +/- 20 %   [Ics] rated service breaking capacity 52.5 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz27 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz22.5 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz9 kA 75 % conforming to EN/IEC 60947-2 - 500 V AC 50/60 Hz25 kA 100 % conforming to EN/IEC 60947-2 - <= 250 V DC   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2   contact position indicator Yes   control type ToggleManual tripping test   local signalling Trip indicatorON/OFF indication   mounting mode Clip-on   mounting support 35 mm symmetrical DIN rail   comb busbar and distribution block compatibility YES   9 mm pitches 6   height 103 mm   width 54 mm   depth 81 mm   net weight 0.48 kg   mechanical durability 20000 cycles   electrical durability 10000 cycles   provision for padlocking Padlockable   locking options description Integrated padlocking   connections - terminals Tunnel type terminals1.5…50 mm² rigidTunnel type terminals1…35 mm² flexible   wire stripping length 20 mm   tightening torque 3.5 N.m   earth-leakage protection Separate block Main - 18723 Miniature Circuit-Breaker range of product NG125   range Acti 9   product name Acti9 NG125   product or component type Miniature circuit-breaker   device short name NG125H   device application Distribution   poles description 3P   number of protected poles 3   [In] rated current 10 A at 40 °C   network type DCAC   trip unit technology Thermal-magnetic   curve code C   breaking capacity 12 kA Icu at 500 V AC 50/60 Hz conforming to EN/IEC 60947-230 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-236 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-270 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-225 kA Icu at <= 375 V DC conforming to EN/IEC 60947-2   utilisation category Category A conforming to IEC 60947-2   suitability for isolation Yes conforming to IEC 60947-2   Complementary network frequency 50/60 Hz   [Ue] rated operational voltage <= 375 V DC380...415 V AC 50/60 Hz500 V AC 50/60 Hz220...240 V AC 50/60 Hz440 V AC 50/60 Hz   magnetic tripping limit 8 x In +/- 20 %   [Ics] rated service breaking capacity 52.5 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz27 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz22.5 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz9 kA 75 % conforming to EN/IEC 60947-2 - 500 V AC 50/60 Hz25 kA 100 % conforming to EN/IEC 60947-2 - <= 375 V DC   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2   contact position indicator Yes   control type ToggleManual tripping test   local signalling Trip indicatorON/OFF indication   mounting mode Clip-on   mounting support 35 mm symmetrical DIN rail   comb busbar and distribution block compatibility YES   9 mm pitches 9   height 103 mm   width 81 mm   depth 81 mm   net weight 0.72 kg   mechanical durability 20000 cycles   electrical durability 10000 cycles   provision for padlocking Padlockable   locking options description Integrated padlocking   connections - terminals Tunnel type terminals1.5…50 mm² rigidTunnel type terminals1…35 mm² flexible   wire stripping length 20 mm   tightening torque 3.5 N.m   earth-leakage protection Separate block Main - 18732 Miniature Circuit-Breaker range of product NG125   range Acti 9   product name Acti9 NG125   product or component type Miniature circuit-breaker   device short name NG125H   device application Distribution   poles description 4P   number of protected poles 4   [In] rated current 10 A at 40 °C   network type DCAC   trip unit technology Thermal-magnetic   curve code C   breaking capacity 12 kA Icu at 500 V AC 50/60 Hz conforming to EN/IEC 60947-230 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-236 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-270 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-225 kA Icu at <= 500 V DC conforming to EN/IEC 60947-2   utilisation category Category A conforming to IEC 60947-2   suitability for isolation Yes conforming to IEC 60947-2   Complementary network frequency 50/60 Hz   [Ue] rated operational voltage 380...415 V AC 50/60 Hz500 V AC 50/60 Hz<= 500 V DC220...240 V AC 50/60 Hz440 V AC 50/60 Hz   magnetic tripping limit 8 x In +/- 20 %   [Ics] rated service breaking capacity 52.5 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz27 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz22.5 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz9 kA 75 % conforming to EN/IEC 60947-2 - 500 V AC 50/60 Hz25 kA 100 % conforming to EN/IEC 60947-2 - <= 500 V DC   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2   contact position indicator Yes   control type ToggleManual tripping test   local signalling ON/OFF indicationTrip indicator   mounting mode Clip-on   mounting support 35 mm symmetrical DIN rail   comb busbar and distribution block compatibility YES   9 mm pitches 12   height 103 mm   width 108 mm   depth 81 mm   net weight 0.96 kg   mechanical durability 20000 cycles   electrical durability 10000 cycles   provision for padlocking Padlockable   locking options description Integrated padlocking   connections - terminals Tunnel type terminals1.5…50 mm² rigidTunnel type terminals1…35 mm² flexible   wire stripping length 20 mm   tightening torque 3.5 N.m   earth-leakage protection Separate block
