Kilowatt Hour Meter NMI DIN 1Ph 100A

Description

Product Features New slimline design Digital LCD display Tamper seal kit supplied 1 year warranty Note - Not suitable for solar applications Specifications Materials: Housing - Fire resistant ABS Weatherproof rating: IP51 Display: Backlit blue LCD Accuracy class: Class 1 Insulation class: Class 2 Maximum rated current: 100 Amp Operational current range: 0.25 - 100 Amp Over current withstand: 1000 Amp for 0.1s Nominal voltage: 230 Vac Operating frequency: 50 - 60 Hz Maximum cable capacity: 25mm2 (neutral 2.5mm2) Operating temperature: -20°C to 65°C Test output flash rate: 1000 impulses per kWh Power supply indicator: Mains power ON Consumption indicator: Flashing on load Dimensions: 90mm (H) x 18mm (W) x 72mm (D) 1 Module Code Packing MOQ Ctn FKW-15110/NMI 1 1 30
