Kilowatt Hour Meter DIN 1Ph 50A

Description

Product Features For single phase direct metering Super compact slimline design 1 year warranty Note - Not suitable for solar applications Specifications Materials: Case - PBT, PC Hook - ABS Weatherproof rating: IP51 Display: Analogue counter, 5+1 = 00000.9kWh Accuracy class: Class 1 Operational current range: 5A - 50A Nominal voltage: 230V ± 20% Operating frequency: 50Hz Starting current: Below 0.004lb Maximum cable capacity: 1 Phase: 10mm2 (neutral 10mm2) Temperature range: -25ºC - +55ºC Power consumption: ≤8VA ≤ 0.4W Impulse indication: Flashing red Impulse constant: 1000imp/kWh Pulse output: Voltage - 12~27V Current - ≤27mA Max length of lead - 20m Impulse width - 90ms Connect to terminals 20 & 21 Limit of values - Max 60VCD, max 50mA Conforms to: EN50470-3:2006, IEC62052-11, IEC62053-21 Dimensions: 120mm (W) x 63mm (H) x 18mmm (H) Code Packing MOQ Ctn FKW-10000 1 1 10
