DSE 800 Series

Description

DSE815 AVR USB to RS485 Converter The DSE815 provides an interface between the AVR and a PC, using an RS485 connection allowing access to the AVR settings via the DSE Configuration Suite PC Software   DIMENSIONS90 mm x 50 mm x 25 mm3.5" x 2" x 1"     DSE813 PC Software Configuration Interface The DSE813 USB Communications Adapter has been developed for use with the DSE103 MKII Speed Switch and the DSE402 MKII Manual/Auto Start Control Modules.  DSE855 USB to Ethernet Communications Device The DSE855 communications device allows monitoring of a single DSE controller with USB connectivity over a LAN or WAN connection. To achieve this the DSE855 utilises its in-built web server or MODBUS TCP. In order to use over a LAN connection the on-site router must be configured to be accessible from any global location.   OVERALL SIZE35 mm x 97 mm x 102 mm (1.4” x 3.8” x 4.0”)WEIGHT0.16kgPRODUCT VARIANTS0855-01 - 855 USB to Ethernet Communications Device DSE857 USB to RS485 Communications Device The DSE857 communications device allows monitoring of a single DSE controller with USB connectivity by converting it to an RS485 connection. To achieve this the DSE857 connects to an RS485 MODBUS RTU master over 1.2km away. The MODBUS RTU master can be an external PLC, Building Management System (BMS) or a Windows PC running the DSE Configuration Suite Software. OVERALL SIZE 35 mm x 97 mm x 102 mm (1.4” x 3.8” x 4.0”)WEIGHT0.16kgPRODUCT VARIANTS0857-01 - 857 USB to RS485 Communications Device DSE890 MKII & DSE891 DSEWebNet® Gateway - 4G (GSM/Ethernet) The DSE890 MKII is an Ethernet/4G gateway device that enables compatible DSE controllers to be monitored remotely via DSEWebNet®. REQUIRES - Combined 4G LTE (Main & Diversity) and GPS Antenna - 020-1053 if 4G Signal is Needed.Unit also fully compatible with 2G & 3G.    OVERALL SIZE85 mm x 149 mm x 51 mm (3.4” x 5.9” x 2.0”)WEIGHT0.23kgPRODUCT VARIANTS0890-04 - 890 DSEWebnet® Gateway - 4G GSM/Ethernet DSE892 Simple Network Management Protocol (SNMP) Gateway The DSE892 connects DSE control modules to external SNMP systems. Once a connection is made full monitoring and control functionality becomes active. The gateway device specialises in monitoring the instrumentation and operating state of the connected DSE control module.    OVERALL SIZE85 mm x 149 mm x 51 mm (3.3” x 5.8” x 2.0”)WEIGHT0.24kgPRODUCT VARIANTS0892-01 - 892 Simple Management Network Protocol (SMNP) Gateway
