DSE 7000 Series

Description

DSE7120MKII Auto Mains (Utility) Failure Control Modules The DSE7120 is an Auto Mains (Utility) Failure Control Module with an icon-based display. The control module has been designed to control single diesel or gas gen-set applications.    OVERALL SIZE240 mm x 181 mm x 42 mm (9.4” x 6.8” x 1.6”) PANEL CUTOUT SIZE220 mm x 160 mm (8.7" x 6.3")MAXIMUM PANEL THICKNESS8.0 mm (0.3”)WEIGHT0.82kgPRODUCT VARIANTS7120-01 - 7120 MKII Auto Mains (Utility) Control Module  DSE7310 MKII Auto Start Control Module The DSE7310 MKII is a powerful, new generation auto start genset control module with a highly sophisticated level of new features and functions, presented in the usual DSE user-friendly format. Suitable for a wide variety of single, diesel or gas Gen-set applications.  OVERALL SIZE 245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")PANEL CUTOUT SIZE220 mm x 160 mm (8.7" x 6.3")MAXIMUM PANEL THICKNESS8.0 mm (0.3")PRODUCT VARIANTS7310-03 - 7310 MKII Autostart Control Module DSE7320 MKII Auto Mains (Utility) Failure Control Module The DSE7320 MKII is a powerful, new generation Auto Mains (Utility) Failure genset control module with a highly sophisticated level of new features and functions, presented in the usual DSE user-friendly format. Suitable for a wide variety of single, diesel or gas Gen-set applications.  OVERALL SIZE245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")PANEL CUTOUT SIZE220 mm x 160 mm (8.7" x 6.3")MAXIMUM PANEL THICKNESS8.0 mm (0.3")PRODUCT VARIANTS7320-03 - 7320 MKII Auto Mains (Utility) Failure Control Module DSE7410 MKII Auto Start Control Module The DSE7410 MKII is an intelligent, powerful auto start control module with high-level features and functionality. The control module is the first module in the DSE range to include in-built SNMP and features an embedded web server. The module is suitable for a wide range of single-set gas and diesel applications.  OVERALL SIZE245 mm x 184 mm x 51 mm (9.6” x 7.2” x 2.0”) PANEL CUTOUT SIZE220 mm x 160 mm (8.7" x 6.3")MAXIMUM PANEL THICKNESS8.0 mm (0.3”)WEIGHT0.88kgPRODUCT VARIANTS7410-03 - 7410 MKII Auto Start Control Module7410-04 - 7410 MKII Auto Start Control Module (Htr) DSE7420 MKII Auto Mains (Utility) Failure Control Module The DSE7420 MKII is an intelligent, powerful auto mains (utility) failure control module with high-level features and functionality. The control module is the first module in the DSE range to include in-built SNMP and features an embedded web server. The module is suitable for a wide range of single-set gas and diesel applications.    READ MORE OVERALL SIZE245 mm x 184 mm x 51 mm (9.6” x 7.2” x 2.0”) PANEL CUTOUT SIZE220 mm x 160 mm (8.7" x 6.3")MAXIMUM PANEL THICKNESS8.0 mm (0.3”)WEIGHT0.88kgPRODUCT VARIANTS7420-03 - 7420 MKII Auto Mains (Utility) Failure Control Module7420-04 - 7420 MKII Auto Mains (Utility) Failure Control Module (Htr)
