Auxiliaries for NG125

Description

  Main - 19064 - Voltage Release range of product Acti 9   product or component type Shunt trip release with OC contact   device short name MX + OF   signal contacts composition 1 C/O   [Ie] rated operational current 3 A at >= 240 V AC6 A at < 240 V AC1 A at 130 V DC2 A at <= 48 V DC6 A at <= 24 V AC   [Uc] control circuit voltage 230...415 V AC 50/60 Hz110...130 V DC   9 mm pitches 2   Complementary range compatibility Vigi NG125Acti9 NG125LMAActi9 NG125NAActi9 NG125   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-5-1   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-5-1   local signalling Action indicator   mounting mode Fixed   mounting support 35 mm symmetrical DIN rail   height 106 mm   width 33 mm   depth 78 mm   net weight 0.129 kg   electrical durability 10000 cycles conforming to EN/IEC 60947-5-1   connections - terminals Plate terminal - 1 cable(s) 0.5…2.5 mm² - rigidPlate terminal - 1 cable(s) 0.5…1.5 mm² - flexiblePlate terminal - 1 cable(s) 0.5…1.5 mm² - flexible with ferrulePlate terminal - 2 cable(s) 2.5 mm² - flexiblePlate terminal - 2 cable(s) 2.5 mm² - rigidPlate terminal - 2 cable(s) 1.5 mm² - flexible with ferrule   wire stripping length 10 mm   tightening torque 1 N.m   compatibility code MX + OF Main - 19067 - Voltage Release range of product Acti 9   product or component type Undervoltage release   device short name MN   [Uc] control circuit voltage 230...240 V AC 50/60 Hz   control type Standard   9 mm pitches 2   Complementary range compatibility Vigi NG125Acti9 NG125LMAActi9 NG125NAActi9 NG125   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-5-1   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-5-1   local signalling Action indicator   mounting mode Fixed   mounting support 35 mm symmetrical DIN rail   height 113 mm   width 32 mm   depth 78 mm   net weight 0.134 kg   electrical durability 10000 cycles conforming to EN/IEC 60947-5-1   connections - terminals Plate terminal - 1 cable(s) 0.5…2.5 mm² - rigidPlate terminal - 1 cable(s) 0.5…1.5 mm² - flexiblePlate terminal - 1 cable(s) 0.5…1.5 mm² - flexible with ferrulePlate terminal - 2 cable(s) 2.5 mm² - flexiblePlate terminal - 2 cable(s) 2.5 mm² - rigidPlate terminal - 2 cable(s) 1.5 mm² - flexible with ferrule   wire stripping length 9 mm10 mm   tightening torque 1 N.m   compatibility code MN Main - 19071 Auxiliary Contact range of product Acti 9   product or component type Double OC contact   device short name OF and OF   signal contacts composition 2 C/O   [In] rated current 3 A: 415 V AC - 50/60 Hz6 A: <= 240 V AC - 50/60 Hz1 A: 130 V DC3 A: <= 48 V DC   9 mm pitches 1   Complementary range compatibility Acti9 NG125NAActi9 NG125LMAActi9 NG125   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-5-1   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-5-1   mounting mode Fixed   mounting support DIN rail   height 102.8 mm   width 15.3 mm   depth 75.5 mm   electrical durability 10000 cycles conforming to EN/IEC 60947-5-1   connections - terminals Plate terminal1 cable(s) 0.5…2.5 mm² - rigidPlate terminal1 cable(s) 0.5…1.5 mm² - flexiblePlate terminal1 cable(s) 0.5…1.5 mm² - flexible with ferrulePlate terminal2 cable(s) 2.5 mm² - rigidPlate terminal2 cable(s) 2.5 mm² - flexiblePlate terminal2 cable(s) 1.5 mm² - flexible with ferrule   wire stripping length 10 mm   tightening torque 1 N.m   Main - 19072 Auxiliary Contact range of product Acti 9   product or component type OC and fault contact   device short name OF and SD   signal contacts composition 2 C/O   [In] rated current 3 A: 415 V AC - 50/60 Hz6 A: <= 240 V AC - 50/60 Hz1 A: 130 V DC3 A: <= 48 V DC   9 mm pitches 1   Complementary range compatibility Acti9 NG125NAActi9 NG125LMAActi9 NG125   [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-5-1   [Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-5-1   mounting mode Fixed   mounting support DIN rail   height 102.8 mm   width 15.3 mm   depth 75.5 mm   electrical durability 10000 cycles conforming to EN/IEC 60947-5-1   connections - terminals Plate terminal1 cable(s) 0.5…2.5 mm² - rigidPlate terminal1 cable(s) 0.5…1.5 mm² - flexiblePlate terminal1 cable(s) 0.5…1.5 mm² - flexible with ferrulePlate terminal2 cable(s) 2.5 mm² - rigidPlate terminal2 cable(s) 2.5 mm² - flexiblePlate terminal2 cable(s) 1.5 mm² - flexible with ferrule   wire stripping length 10 mm   tightening torque 1 N.m
