Add on Vigi Blocks for C120 -

Description

Main A9N18572 Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 2P [In] rated current: 125 A Network type: AC Earth-leakage sensitivity: 30 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 230...240 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 7 Height: 95 mm Width: 117 mm Depth: 73 mm Product weight: 0.325 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m Main A9N18573 Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 2P [In] rated current: 125 A Network type: AC Earth-leakage sensitivity: 300 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 230...415 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 7 Height: 95 mm Width: 117 mm Depth: 73 mm Product weight: 0.325 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m Main A9N18578 Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 4P [In] rated current: 125 A Network type: AC Earth-leakage sensitivity: 30 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 400...415 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 10 Height: 95 mm Width: 198 mm Depth: 73 mm Product weight: 0.58 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m Main A9N18579 Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 4P [In] rated current: 125 A Network type: AC Earth-leakage sensitivity: 300 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 230...415 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 10 Height: 95 mm Width: 198 mm Depth: 73 mm Product weight: 0.58 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m Main A9N18575  Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 3P [In] rated current: 125 A Network type: AC Earth-leakage sensitivity: 30 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 400...415 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 10 Height: 95 mm Width: 171 mm Depth: 73 mm Product weight: 0.5 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m Main A9N18576 Product or component type: Add-on residual current devices Device short name: Vigi C120 Poles description: 3P [In] rated current: 125 A Network type: AC . Earth-leakage sensitivity: 300 mA Earth-leakage protection time delay: Instantaneous Earth-leakage protection class: Type A Complementary Device location in system: Outgoer Network frequency: 50/60 Hz [Ue] rated operational voltage: 230...415 V AC 50/60 Hz Residual current tripping technology: Voltage independent [Ui] rated insulation voltage: 500 V AC 50/60 Hz conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 Mounting mode: Clip-on Mounting support: 35 mm symmetrical DIN rail Electrical connection to mcb: By screws 9 mm pitches: 10 Height: 95 mm Width: 171 mm Depth: 73 mm Product weight: 0.5 kg Colour: White Mechanical durability: 20000 cycles Connections - terminals: Tunnel type terminals 1…35 mm² flexible, Tunnel type terminals 1…50 mm² rigid Wire stripping length: 15 mm Tightening torque: 3.5 N.m
