ACTI9 Motor-heating-lighting
SKU: bc-595
$61.99
Currently out of stock — contact us for lead times
Description
Main - A9C20134 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 4 NO network type AC control type Remote control [Uc] control circuit voltage 24 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 1.6 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTpIACTsIACTcIATEt compatibility code ICT market segment Small commercialResidential Main A9C20731 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 1P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 1 NO network type AC control type Remote control [Uc] control circuit voltage 230...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.2 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 2.7 VA inrush power in VA 9.2 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 2 height 81 mm width 18 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTcIACTsIATEtIACTp compatibility code ICT market segment Small commercialResidential Main - A9C20732 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 2 NO network type AC control type Remote control [Uc] control circuit voltage 230...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.2 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 2.7 VA inrush power in VA 9.2 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 2 height 81 mm width 18 mm depth 68.5 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTsIACTpIACT 24IATEtIACTc compatibility code ICT market segment ResidentialSmall commercial Main - A9C20736 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 2 NC network type AC control type Remote control [Uc] control circuit voltage 230...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.2 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 2.7 VA inrush power in VA 9.2 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 2 height 81 mm width 18 mm depth 68.5 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTcIACTsIACTpIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20833 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 3P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 3 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 1.6 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTcIACTpIACTsIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20834 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 4 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 1.6 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IATEtIACTsIACTcIACTp compatibility code ICT market segment Small commercialResidential Main - A9C20837 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 4 NC network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 1.6 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTsIATEtIACTcIACTp compatibility code ICT market segment ResidentialSmall commercial Main - A9C20838 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 25 A AC-7A8.5 A AC-7B pole contact composition 2 NO + 2 NC network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 1.6 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 25 A 50 Hz AC-7A30000 cycles IEC/EN 61095 8.5 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTcIATEtIACTpIACTs compatibility code ICT market segment Small commercialResidential Main - A9C20842 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 40 A AC-7A15 A AC-7B pole contact composition 2 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.6 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 85 mm width 36 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 40 A 50 Hz AC-7A30000 cycles IEC/EN 61095 15 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTcIACTsIACTpIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20843 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 3P [Ie] rated operational current 40 A AC-7A15 A AC-7B pole contact composition 3 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 40 A 50 Hz AC-7A30000 cycles IEC/EN 61095 15 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTsIATEtIACTcIACTp compatibility code ICT market segment ResidentialSmall commercial Main - A9C20844 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 40 A AC-7A15 A AC-7B pole contact composition 4 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 40 A 50 Hz AC-7A30000 cycles IEC/EN 61095 15 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTpIATEtIACTcIACTs compatibility code ICT market segment ResidentialSmall commercial Main - A9C20847 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 40 A AC-7A15 A AC-7B pole contact composition 4 NC network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 40 A 50 Hz AC-7A30000 cycles IEC/EN 61095 15 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTpIACTcIACTsIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20862 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 63 A AC-7A20 A AC-7B pole contact composition 2 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.6 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 4.6 VA inrush power in VA 34 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 85 mm width 36 mm depth 68.5 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 63 A 50 Hz AC-7A30000 cycles IEC/EN 61095 20 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTpIATEtIACTsIACTc compatibility code ICT market segment ResidentialSmall commercial Main - A9C20863 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 3P [Ie] rated operational current 63 A AC-7A20 A AC-7B pole contact composition 3 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 68.5 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 63 A 50 Hz AC-7A30000 cycles IEC/EN 61095 20 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTcIACTpIACTsIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20864 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 63 A AC-7A20 A AC-7B pole contact composition 4 NO network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 63 A 50 Hz AC-7A30000 cycles IEC/EN 61095 20 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTsIATEtIACTcIACTp compatibility code ICT market segment Small commercialResidential Main - A9C20867 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 63 A AC-7A20 A AC-7B pole contact composition 4 NC network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 63 A 50 Hz AC-7A30000 cycles IEC/EN 61095 20 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTpIACTsIACTcIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20868 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 4P [Ie] rated operational current 63 A AC-7A20 A AC-7B pole contact composition 2 NO + 2 NC network type AC control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power 2.1 W at 400 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 63 A 50 Hz AC-7A30000 cycles IEC/EN 61095 20 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 6…16 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…25 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 3.5 N.m product compatibility IACTpIACTcIACTsIATEt compatibility code ICT market segment Small commercialResidential Main - A9C20882 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Heating-low inductive load Poles 2P [Ie] rated operational current 100 A AC-7A pole contact composition 2 NO network type AC utilisation category AC-1 conforming to EN 60947-4-1AC-7A conforming to EN 61095AC-7A conforming to IEC 61095AC-7A conforming to UTE C 61-481AC-1 conforming to IEC 60947-4-1 control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power AC-7A: 2.1 W at 250 V AC 50 Hz [Ui] rated insulation voltage 500 V AC 50 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 6.5 VA inrush power in VA 53 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 6 height 85 mm width 54 mm depth 60 mm colour White electrical durability 30000 cycles EN 61095 250 V 16 A AC 50 Hz AC-7A30000 cycles UTE C 61-481 250 V 6 A AC 50 Hz AC-7A30000 cycles IEC 61095 250 V AC 50 Hz AC-7A connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…35 mm² solid or flexible tightening torque Power circuit: 3.5 N.mControl circuit: 0.8 N.m A1 / A2 product compatibility IACTsIACTpIATEtIACTc compatibility code ICT market segment Small commercialResidential Main - A9C20884 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Heating-low inductive load Poles 4P [Ie] rated operational current 100 A AC-7A pole contact composition 4 NO network type AC utilisation category AC-1 conforming to EN 60947-4-1AC-7A conforming to EN 61095AC-7A conforming to IEC 61095AC-7A conforming to UTE C 61-481AC-1 conforming to IEC 60947-4-1 control type Remote control [Uc] control circuit voltage 220...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 400 V AC 50 Hz maximum power AC-7A: 4.2 W at 400 V AC 50 Hz [Ui] rated insulation voltage 500 V AC 50 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 13 VA inrush power in VA 106 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 12 height 85 mm width 108 mm depth 60 mm colour White electrical durability 30000 cycles EN 61095 400 V 16 A AC 50 Hz AC-7A30000 cycles UTE C 61-481 400 V 6 A AC 50 Hz AC-7A30000 cycles IEC 61095 400 V AC 50 Hz AC-7A connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 6…35 mm² solid or flexible tightening torque Power circuit: 3.5 N.mControl circuit: 0.8 N.m A1 / A2 product compatibility IACTpIACTsIATEtIACTc compatibility code ICT market segment Small commercialResidential Main - A9C22712 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 16 A AC-7A6 A AC-7B pole contact composition 2 NO network type AC control type Remote control [Uc] control circuit voltage 230...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.2 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 2.7 VA inrush power in VA 9.2 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 2 height 81 mm width 18 mm depth 68.5 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 16 A 50 Hz AC-7A30000 cycles IEC/EN 61095 6 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTs compatibility code ICT market segment Small commercialResidential Main -A9C22715 range of product Acti9 product name Acti9 iCT product or component type Contactor device short name ICT device application Motor-heating-lighting Poles 2P [Ie] rated operational current 16 A AC-7A6 A AC-7B pole contact composition 1 NO + 1 NC network type AC control type Remote control [Uc] control circuit voltage 230...240 V AC 50 Hz Complementary network frequency 50 Hz [Ue] rated operational voltage 250 V AC 50 Hz maximum power 1.2 W at 250 V AC [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control signal type Maintained switching frequency 100 switching operations/day local signalling Action indicator hold-in power consumption in VA 2.7 VA inrush power in VA 9.2 VA mounting mode Clip-on mounting support 35 mm symmetrical DIN rail 9 mm pitches 2 height 81 mm width 18 mm depth 60 mm colour White mechanical durability 1000000 cycles electrical durability 100000 cycles IEC/EN 61095 16 A 50 Hz AC-7A30000 cycles IEC/EN 61095 6 A 50 Hz AC-7B30000 cycles IEC/EN 61095 50 Hz AC-7C100000 cycles EN/IEC 60947-4-1 50 Hz AC-130000 cycles EN/IEC 60947-4-1 50 Hz AC-330000 cycles EN/IEC 60947-4-1 50 Hz AC-5a30000 cycles EN/IEC 60947-4-1 50 Hz AC-5b connections - terminals Control circuit: tunnel type terminals2 cable(s) 1.5 mm² rigidPower circuit: tunnel type terminals1 cable(s) 1…4 mm² flexiblePower circuit: tunnel type terminals1 cable(s) 1.5…6 mm² rigidControl circuit: tunnel type terminals1 cable(s) 1.5…2.5 mm² rigidControl circuit: tunnel type terminals2 cable(s) 1.5…2.5 mm² flexible tightening torque Control circuit: 0.8 N.mPower circuit: 0.8 N.m product compatibility IACTs compatibility code ICT market segment ResidentialSmall commercial
